Maincor UFH Products

Maincor Products

Underfloor Heating System

PE-RT pipe with EVOH (5-layer) 16 x 2,0 / 600 m

The NEOflex pipe has been consistently further developed with regard to installation comfort and mechanical resistance.
We grant a 15-year warranty.

Pressure-resistant, according to DIN 4726 oxygen impermeable pipe PE-RT, in coils. The material used is non-cross-linked polyethylene with a higher temperature resistance (PE-RT, raised temperature according to DIN 16833). Can be used for heating and radiant heating installation.

Application class (ISO 10508):
4 / 6 bar

Made in Germany

PE-RT pipe with EVOH (5-layer) 16 x 2,0 / 600 m

The NEOflex pipe has been consistently further developed with regard to installation comfort and mechanical resistance.
We grant a 15-year warranty.

Application class (ISO 10508):
4 / 6 bar

Made in Germany

PE-RT pipe with EVOH (5-layer) 16 x 2,0 / 600 m

The NEOflex pipe has been consistently further developed with regard to installation comfort and mechanical resistance.
We grant a 15-year warranty.

Application class (ISO 10508):
4 / 6 bar

Made in Germany

MFL Composite pipe PE-RT / Alu / PE-RT 16 x 2,0 / 500 m

Pressure-resistant, according to DIN 4726 oxygen impermeable multi layer composite pipe (MLCP), in coils.

Structure of the pipe:
PE-RT – adhesive – aluminium layer – adhesive – PE-RT

The material used is non-cross-linked polyethylene with a higher temperature resistance (PE-RT, raised temperature according to DIN 16833). Can be used for heating and radiant heating installation. Checked and monitored by the SKZ.
Application class (ISO 10508):
4.5 / 6 bar

Made in Germany

MPR / MFL Compression fitting 16 x 2,0 x 3/4"

Compression fitting made of brass to connect underfloor heating pipes with manifolds or valves (both with 3/4" eurocone)

MFL Distribution cabinet, in-wall110 - 140 mm deep UP 8 (684 mm)

Distribution cabinet, in-wall made out of galvanised steel sheet with height-adjustable installation frame made of hot-dip galvanised steel sheet. With adjustable and removable frame with removable door and turning bolt. Powder coated RAL 9016.

Depth: 110 - 140 mm
Height: 716 mm - 896 mm
Height adjustable cabinet feet, up to 180 mm
Without cylinder lock.

MFL Manifold stainless steel with integrated flow meter 1“ long 2 Circuits

Supply block:
Fluid flow meter 0-5 l/min (Tacconova), flow rate can be set and read off without tools

Included:
• 1 set of loop labels; two flat-seals 1“ fitting ball valves:
• 3/4" female thread x 1" male thread flat-sealing for underfloor heating with max. 7 loops
• 1“ female thread x 1“ male thread for all underfloor heating

MFL Ball valve 1“ FT x 1“ + 1" * 1/4 MT

To block a stainless steel manifold, male thread flat-sealing, including gaskets. VE consists of two ball valves (1x red and 1x blue).
Material: Brass, nickel plated

Set consists of a corner-ball valve 1" female thread x 1" male thread flat-sealing with an extended structure (blue), construction length 125 mm, and a corner-ball valve 1" female thread x 1" male thread flat-sealing (red).

MPR / MFL Press coupler for the connection of floor heating pipes 16 x 16

To connect heating pipe PE-RT / Alu / PE-RT and heating pipe PE-RT of DIM 16 x 2.0 and heating pipe PE-RT with DIM 20 x 2.0.

Coupler/coupling consisting of brass, corresponding to the DVGW and ÖVGW requirements. Surface coated with tin according to DVGW worksheet W 534. Suitable for use in heating and sanitary areas. Profile ring made of EPDM (certified by DVGW) with elbow segment profile. Stainless-steel press sleeve with a plastic stop ring, both firmly bonded with the fitting. The press slee.

MFL Constant control kit 1" incl. Ball valve

One-part regulation station designed for a maximum power transfer of up to 10 kW (∆t=10K) or a maximum flow volume of 1.3 m³/h (approx. 150 m² heating surface).

Consisting of:
• Mixing valve
• Circulation pump
• Safety temperature limiter
• 2 ball valves
• 1“ connections for direct flange-mounting to the manifold with 1“ joint union nut
• Pump: Taco Flow 2, rated voltage 230 V

MFL Pipe positioning panel premium 14 - 17 mm Panel without insulation

Pipe positioning panel for pipe diameter 14 - 17 mm, consisting of a deep-drawn multi-functional film with back-foamed pipe mount studs (item no. 51.903.060 without) which guarantees the secure mounting of pipes, mandatory pipe connection to adhere to the prescribed installation distances, density and very good walk-on stability. The direct back-foaming creates a firm bond between the pipe positioning panel and the EPS thermal insulation or EPS thermal and footfall sound insulation.

MFL Actuator NEO 230V

Further development of the standard model. Small, compact design, manual adjustment mechanism, water protection according to protection type IPX4. Also suitable for overhead mounting. Display of operating status and stroke position. Suitable without adapter, low diameter. 230 V, joint union nut M 30 x 1.5 mm, free cable end with ferrules, length = 0,8 m. Actuator closed and currentless 230 V AC 2.0 W

Power stroke: 4.0 mm
Dimensions: 69 mm x 37 mm

MFL Actuator 4.0 230V

Small, compact design, water protection according to protection type IP54. Also suitable for overhead mounting. Display of operating status and stroke position. Includes an adapter for all MAINCOR manifolds. Joint union nut M30 x 1.5 mm. Free cable end with ferrules. Length = 1 m, actuator closed and currentless. With first-open function.

Power stroke: 4 mm
Dimensions: 59.1 mm x 49.4 mm

MFL Digital controller standard (for heating) 230V

Room thermostat for wall fastening with temperature display. Simple and intuitive operation with the rotary knob. Input for lowered channel.

MFL Pipe guide bend 10 - 18

Pipe guide bend consisting of polyethylene (PE), not flame-resistant, free from halogens. Resistant to nearly all media (alcohols, grease, mineral oils, fuels), however not resistant to concentrated, strong oxidising acids. The pipe guide bend 20 with item no. 50.903.237 is recommended for use with the main pipe PE-RT 16 x 1.5.
Application temperature of the elbow:
Continuous load -15°C to 90°C
Short-term load up to 120°C

MFL Wired control center standard 230V / 24V 6 zones - 10 zones

Control center for the proper wiring of temperature regulators and electro-thermal actuators.
No-screw control center connection technology. Lowered channel. Connection for external 2-channel timer.
24 V or 230 V is determined by the installation of the accompanying glass fuse.

Max. number of actuators that can be connected for 230 V control center:
For 6 zones = 15 MAINCOR actuators
For 10 zones = 18 MAINCOR actuators

Max. rated load of all drives
At 24 V = 24 W

MFL Edge - insulation strip 8 x 150 mm self-adhesive tape

Marginal insulating strips for the standard-compliant separation of the creed from adjacent components in floor constructions according to DIN 18560 and DIN EN 1264, with laminated PE foil for sealing particularly with liquid screeds.

Colour shown may differ from the original!

MFL Manual fixing pin 45 mm

Plastic manual pipe fixing pin (PE), to fasten the fixing rail to the plastic foil with rasterorientation, with the underlying insulating layer, can also be used for the additional fastening of system pipes.

MFL U-Clips, stored 14 - 20 mm / length 40 mm

U-Clips made of plastic (PE) to fasten the system pipe onto the suitable substrate (underfloor heating staple system).

Suitable for pipes of 14 - 20 mm.
Processing with a tacker tool.

Flamco

Kombibox RTL white underfloor heating

First Item

Add a description about this item

Second Item

Add a description about this item

hird ItemT

Add a description about this item

First Item

Add a description about this item

Second Item

ONNINEN index:HAM568Manufacturer's code:F11878

List of old codes:

11878

EAN:4013852210981Customs code:84819000Series:RTLProduct type:rtlVAT:23%Packaging:1 / 70 pcs

Sales unit dimensions and weight: 1 pcs

length/width/height/weight/volume:0,228 m / 0,121 m / 0,224 m / 0,918 kg / 0,006 m3

Made in Germany

Direct Supply from Germany

MAINCOR GmbH, Silbersteinstrasse 14, 97424 Schweinfurt
